Does Redding clay soil crack concrete patios

On clay that swells in the wet months and shrinks in the dry heat, a patio slab never sits still, and demolition work in Redding, CA (laid out at redding demolition evrnyc) usually begins with reading what the soil has already done to the concrete. Most cracked patios were not poured badly. They were poured on ground that moves.

How clay moves a slab

Clay takes on water through winter and expands, pushing upward. Through summer it dries, shrinks and pulls away, leaving a void under the concrete slab. Patios in Shasta County neighbourhoods near Turtle Bay and Anderson often show both at once: a high corner where a downspout dumps water, and a hollow sound underfoot where the slab has lost its support.

Reading the cracks

A single straight crack through the middle usually means a slab with no control joints that has simply let go. A crack that runs corner to corner points to one corner sinking. Step cracks where one side sits half an inch higher than the other point to heave. A map of fine cracks across the surface is a finish problem and says little about the soil.

Why this changes the removal

A slab sitting on a void breaks easily and falls into the gap, which is fine with a jackhammer but dangerous with a machine that rolls onto it. A slab that has heaved is under stress, and it can kick when the first cut releases it. The first breaks go on the thinnest, most broken section, working toward the stiff areas.

What is left in the ground

Once the concrete is gone, the clay below is wet, sticky and uneven. A skid steer with a bucket scrapes it flat, and anything soft is dug out. Replacement concrete poured straight onto churned clay will crack the same way, so the subgrade gets compacted and topped with a layer of crushed base before anything new is poured.

Where it meets the house

A patio that has pulled away from a wall or tilted toward the foundation sends water to the one place it should not go. The joint at the house wall is cut with a saw before breaking starts, so the foundation and its stucco or siding are not chipped by a breaker working too close.
